Flexible Connector for FCU-AHU with Brass Ends

Easyflex EFFCB stainless steel braided elastomeric hose is a convenient and economical way to provided a flexible connection between mechanical equipment and water piping Braided hose.

Features:

  • High grade, durable EPDM hose with SS304 Braiding
  • Designed for high working pressures
  • Available with end fittings to suit any type of equipment / pipe connection or pipe material
  • Hoses for reducing connections can also be supplied on request
  • Swivel BSP end connection supplied complete with EPDM gasket on end and fixed male BSP on other end
  • Excellent stress reversal characteristics

Easyflex EFFCB stainless steel braided elastomeric hose is a convenient and economical way to provided a flexible connection between mechanical equipment and water piping Braided hose.

Printable Pages:

NPS Size Length Working Pressure Working Temperature Test Pressure BEND RADIUS (MINIMUM) Drawing
NB mm/inch barg/Psig ⁰C/⁰F barg/Psig mm/inch
1/2 15 305/12 25/362.6 110/230 37.5/544 80/3.15 Click here
1/2 15 457/18 25/362.6 110/230 37.5/544 80/3.15 Click here
1/2 15 660/26 25/362.6 110/230 37.5/544 80/3.15 Click here
1/2 15 914/36 25/362.6 110/230 37.5/544 80/3.15 Click here
1/2 15 1219/48 25/362.6 110/230 37.5/544 80/3.15 Click here
3/4 20 305/12 25/362.6 110/230 37.5/544 100/3.94 Click here
3/4 20 457/18 25/362.6 110/230 37.5/544 100/3.94 Click here
3/4 20 660/26 25/362.6 110/230 37.5/544 100/3.94 Click here
3/4 20 914/36 25/362.6 110/230 37.5/544 100/3.94 Click here
3/4 20 1219/48 25/362.6 110/230 37.5/544 100/3.94 Click here
1 25 305/12 16/232 110/230 24/348 125/4.92 Click here
1 25 457/18 16/232 110/230 24/348 125/4.92 Click here
1 25 660/26 16/232 110/230 24/348 125/4.92 Click here
1 25 914/36 16/232 110/230 24/348 125/4.92 Click here
1 25 1219/48 16/232 110/230 24/348 125/4.92 Click here
